NERC Reliability Standard PRC-024-3 Approved: Frequency and Voltage Protection Settings for Generating Resources

On July 9, 2020 NERC standard PRC-024-3 was approved, paving the way for improved protection systems in support of keeping generating resources connected during defined frequency and voltage excursions. The standard has a two-year implementation plan. Immediately prior to its effective date, PRC-024-02 will be retired.

PRC-024-3 clarifies the voltage and frequency protection setting requirements to assure that generating resources, including inverter-based resources, continue to support power system stability during system disturbances. The standard identifies the types of protection subject to the requirements and incorporates language used by inverter manufacturers and solar project developers, while ensuring correct protection settings for applicable generating resources.

PRC-024-2 standard was revised to address recommendations made by the NERC Inverter-Based Resource Performance Task Force (IRPTF) which were developed in response to NERC and WECC analysis of the Blue Cut Fire and Canyon 2Fire disturbances in southern California. Event analysis for both disturbances revealed that misinterpretation of the requirements of PRC-024-2 led to the intentional and unnecessary tripping of solar PV resources during these events. In addition to identifying the need to provide clarity around the intent and requirements in PRC-024-2, the IRPTF also found errors within the standard.

The expectations of generators regarding adherence to the no-trip boundaries for both system frequency and system voltage excursions for each interconnection in North America are the key technical components of the standard.

Next Steps for Successful Compliance

NERC standards are the minimum obligations that must be met for utility for reliable operation of the Bulk Electric System. Now is the time to begin planning for the changes needed to your company’s processes and procedures to implement the revised standard within your compliance program.

Utilities should evaluate their programs and processes in order to stay ahead of regulatory changes. Now is the time to consider what support you might need for further NERC Compliance program development, independent compliance assessment, pre-audit reviews and compliance documentation.

Resources

• PRC-024-3 Standard
• FERC PRC-024-3 Approval Letter
• NERC Petition to FERC for Approval of PRC-024-3
• PRC-024-3 Implementation Plan
• NERC PRC-024 Gaps Whitepaper
• TRC Regulatory Update on PRC Standard Changes 9-24-2019
• TRC Protection and Control Services
• TRC Compliance Support
